1 1/2 LFAFBV-FP-T

Item Number: 88005711
1 1
$801.00
Special Order
When Will it Ship: Contact for Lead Time
Estimated transit time: 2 to 5 Business Days

Brand - Ames
  • Valve Size: 1 1/2 inch
  • Weight: 18.1 lb
  • Connection Type: Female NPT Threaded
  • Body Material: Lead Free Copper-Silicon Alloy
  • Working Pressure (UL/FM): 400 psi
  • Working Pressure (WOG): 600 psi
  • Integrated Supervisory Switches: Yes
  • Operation: Slow Close, Gear Operated Quarter-Turn
  • Approvals: UL Listed, FM Approved, NSF Certified

Description

This 1 1/2 inch Lead Free Gear Operated Ball Valve with NPT threaded ends is designed for fire protection systems. UL/FM rated for 400 psi, it features a 2-piece lead free copper silicon alloy body, chrome-plated brass ball, and PTFE seats. Integrated supervisory switches can be wired Normally Open or Normally Closed, and the slow-close gear operation helps prevent water hammer. Suitable for indoor and outdoor use, this valve meets NFPA 13 Section 6.7.1, UL, FM, and NSF/ANSI 372 standards. Item number 88005711.

Help Me Connect

Connecting this 1 1/2 inch LFAFBV-FP-T Ball Valve

  • This valve features 1 1/2 inch Female NPT threaded ends for connection to corresponding 1 1/2 inch Male NPT threaded pipes or fittings.
  • Ensure proper thread sealant is used for a secure and leak-free installation, following industry best practices for NPT connections.
View full details

Additional Details

This 1 1/2 inch full port gear operated ball valve is UL/FM rated for 400psi service in fire protection systems. It features 2-piece lead free construction with NPT threaded ends, integrated supervisory switches, and a mechanical indicator flag. The valve is suitable for both indoor and outdoor applications.

Features

  • Slow open and slow closing operation helps to eliminate water hammer.
  • Can be wired as either Normally Open or Normally Closed.
  • Reversible supervisory switch box simplifies electrical wiring access.
  • Gear operated quarter-turn operation for precise control.
  • Includes two standard internal tamper switches.
  • Conforms to NFPA 13 Section 6.7.1.
  • Designed with a clockwise-to-close handle and ergonomic handle design.

Specifications

  • Valve Type: Ball Valve
  • Body Material: Lead Free Copper-Silicon Alloy
  • Ball Material: Chrome Plated Brass
  • Seats Material: Virgin PTFE
  • Stem Material: Brass
  • Stem Packing Material: Virgin PTFE
  • Stem O-Ring Material: EPDM
  • Box/Cover Material: Bronze ASTM B584 Alloy 844
  • Yoke Material: LEAD-FREE Copper Silicon Alloy
  • Screw Material: Brass
  • Traveler Nut Material: Brass
  • Nominal Size: 1 1/2 inch
  • Connection Type: Female NPT threaded ends
  • Working Pressure (UL/FM Rated): 400 psi (27.6 bar)
  • Maximum Work Pressure (WOG): 600 psi (41.4 bar)
  • Hydrostatic Test Pressure: 900 psi (62.0 bar)
  • Temperature Range: 33°F - 180°F (0.5°C - 82°C)
  • Switch Type: Integrated Tamper Switches

Certificates & Approvals

  • UL Listed
  • FM Approved
  • NSF Certified to NSF/ANSI 372
  • NFPA 11, 13, 14, 15, 16, 20, 22, and 24 Compliant
  • Compliant to ANSI/ASME B1.20.1
  • Conforms to NFPA 13 Section 6.7.1

FAQs

What is the primary use of this 1 1/2 inch LFAFBV-FP-T ball valve?

This 1 1/2 inch full port gear operated ball valve is primarily used in fire protection systems, being UL/FM rated for 400 psi service.

What type of connections does this valve have?

This valve is equipped with 1 1/2 inch female NPT threaded ends, compliant to ANSI/ASME B1.20.1 for standard thread connections.

What does 'Lead Free' mean for this product?

The 'Lead Free' designation means that the wetted surface of this product contacted by consumable water contains less than 0.25% of lead by weight, complying with reduced lead content requirements.

Are the supervisory switches pre-wired or can they be configured?

The integrated supervisory switches can be wired as either Normally Open or Normally Closed, offering flexibility for various electrical wiring configurations. The reversible switch box simplifies access.

What is the maximum operating temperature for this ball valve?

This ball valve has an approved operating temperature range of 33°F to 180°F (0.5°C to 82°C).
