1 1/4" x 1" Lead Free Brass Bushing
Item Number: 15287
1
/
of
1
Regular price
$14.72
Limited Stock
(6)
Estimated transit time: 2 to 5 Business Days
Eligible for Express Shipping
Brand - Matco-Norca
Couldn't load pickup availability
- Size: 1-1/4" Male NPT x 1" Female NPT
- Weight: 0.35 lb
- Material: ASTM B584, Alloy C89833 Lead Free Brass
- Fitting Class: 125 lbs
- Thread Standard: ASME B1.20.1 NPT
- Approvals: NSF 61, NSF 372
- Overall Length: 0.80 inches
- Lead Free: Yes
Description
Description
This 1 1/4 inch x 1 inch lead-free brass bushing is a durable fitting for reducing pipe connections in potable water and industrial systems. Constructed from ASTM B584, Alloy C89833 lead-free brass, it ensures safety for drinking water applications with NSF 61 and NSF 372 approvals. The bushing features 1-1/4 inch male NPT threads and 1 inch female NPT threads, conforming to ASME B1.20.1 standards for reliable installation. Rated as a Class 125 lbs fitting, it is suitable for various plumbing needs requiring a secure, corrosion-resistant connection. Item number 15287.

Collapsible content
Additional Details
This is a 1 1/4 inch x 1 inch lead-free brass bushing designed to reduce the size of a threaded connection in plumbing and industrial applications.
It features male and female NPT threads for secure and adaptable pipe connections.
Key Features
- Constructed from lead-free brass alloy C89833 for potable water safety.
- Class 125 lbs fitting suitable for various low-pressure systems.
- Designed to ASME B1.20.1 thread standards ensuring compatibility.
- NSF 61 and NSF 372 approved for drinking water applications.
Specifications
- Fitting Type: Bushing
- Size: 1-1/4 inch Male NPT x 1 inch Female NPT
- Material: ASTM B584, Alloy C89833 Lead Free Brass
- Fitting Class: 125 lbs
Dimensions
- Overall Length (A): 0.80 inches
- Hex Height (B): 0.28 inches
- Thread Engagement Length (C): 1.76 inches
- Dimensional Standards: ASME B16.15, B16.18
Certificates & Approvals
- NSF 61
- NSF 372
Thread Standards
- Thread Type: NPT (National Pipe Taper)
- Thread Standard: ASME B1.20.1
FAQs
What is the primary purpose of this 1 1/4" x 1" Lead Free Brass Bushing?
This bushing is designed to reduce the size of a threaded pipe connection, allowing a 1-1/4 inch male NPT fitting to connect to a 1 inch female NPT opening.
What material is this bushing made from?
It is made from ASTM B584, Alloy C89833 lead-free brass, ensuring it is safe for use in potable water systems.
What are the thread specifications for this bushing?
The bushing features NPT (National Pipe Taper) threads that conform to ASME B1.20.1 standards, providing a reliable and leak-resistant seal.
Is this brass bushing approved for drinking water applications?
Yes, this lead-free brass bushing is approved by NSF 61 and NSF 372, making it suitable for potable water use.
What is the fitting class of this bushing?
This is a Class 125 lbs fitting, indicating its pressure rating and suitability for standard plumbing and industrial applications.
