1 LFAFBV-FP-T

Item Number: 88005710
1 1
$629.99
Special Order
When Will it Ship: Contact for Lead Time
Estimated transit time: 2 to 5 Business Days

Brand - Ames
  • Nominal Pipe Size: 1 inch
  • Weight: 33.3 lb
  • Connection Type: Female NPT Threaded
  • Body Material: Lead Free Copper-Silicon Alloy
  • Working Pressure (UL/FM): 400 psi
  • Slow-Close Gear Operation: Prevents water hammer
  • Integrated Supervisory Switches: Normally Open or Normally Closed
  • Approvals: UL Listed, FM Approved, NSF Certified
  • Temperature Range: 33°F - 180°F

Description

This 1 inch Ames LFAFBV-FP-T full port gear operated ball valve is engineered for fire protection systems, featuring a lead-free copper silicon alloy body and chrome-plated brass ball. It is UL/FM rated for 400 psi and designed for both indoor and outdoor use. The slow-close gear operation prevents water hammer, while integrated supervisory switches with a reversible box allow wiring as normally open or normally closed. This valve features female NPT threaded ends and conforms to NFPA 13 Section 6.7.1, ensuring reliable performance and compliance. Item number 88005710.

Help Me Connect

Connections

This 1 inch full port ball valve features female NPT threaded ends designed for connection to male NPT threaded pipes. It is compatible with Schedule 40 pipe for fire protection systems. The integrated tamper switches require electrical wiring for supervisory functions, with a reversible switch box to simplify access for either Normally Open or Normally Closed applications.

View full details

Additional Details

This 1 inch full port gear operated ball valve from Ames Fire & Waterworks is designed for fire protection systems, featuring a slow-close mechanism to eliminate water hammer and integrated supervisory switches for system monitoring.

It is UL/FM rated for 400 psi service and suitable for both indoor and outdoor applications.

Features

  • Lead-free cast copper silicon alloy body construction.
  • Machined chrome plated lead-free brass ball for durability.
  • Slow-close gear operation prevents water hammer.
  • Integrated supervisory switches with a reversible switch box for simplified electrical wiring.
  • Switches can be wired as either Normally Open or Normally Closed.
  • Quarter-turn operation with an ergonomic, clockwise-to-close handle.
  • Includes two standard internal tamper switches.
  • Female NPT threaded ends for secure installation.
  • Conforms to NFPA 13 Section 6.7.1.

Specifications

  • Valve Type: 2-Piece, Full Port Ball Valve
  • Nominal Pipe Size: 1 inch
  • Body Material: Lead Free Copper-Silicon Alloy
  • Ball Material: Chrome Plated Brass
  • Seat Material: Virgin PTFE
  • Stem Material: Brass
  • Stem Packing Material: Virgin PTFE
  • Stem O-Ring Material: EPDM
  • Box/Cover Material: Bronze ASTM B584 Alloy 844
  • Yoke Material: LEAD-FREE Copper Silicon Alloy
  • Screw Material: Brass
  • Traveler Nut Material: Brass
  • Connection Type: Female NPT Threaded
  • Operation: Gear Operated Quarter-Turn
  • Handle Operation: Clockwise-to-Close
  • Rated Working Pressure (UL/FM): 400 psi (27.6 bar)
  • Maximum Work Pressure (WOG): 600 psi (41.4 bar)
  • Hydrostatic Test Pressure: 900 psi (62.0 bar)
  • Temperature Range: 33°F - 180°F (0.5°C - 82°C)

Certificates & Approvals

  • UL Listed
  • FM Approved
  • NSF Certified to NSF/ANSI 372
  • NFPA Compliant: 11, 13, 14, 15, 16, 20, 22, 24
  • Conforms to ANSI/ASME B1.20.1

FAQs

What is the primary application of this ball valve?

This ball valve is primarily used in fire protection systems, being UL/FM rated for 400 psi service for both indoor and outdoor applications. Its design features support reliable operation in critical fire safety infrastructures.

Is this valve compliant with lead-free standards?

Yes, it features a Lead-Free cast copper silicon alloy body and a chrome-plated lead-free brass ball. The wetted surface contacted by consumable water contains less than 0.25% of lead by weight, ensuring compliance with reduced lead content standards.

How do the supervisory switches function?

The integrated supervisory switches can be wired as either Normally Open or Normally Closed, and they come with a reversible switch box to simplify electrical wiring access for monitoring valve position, enhancing system integrity.

What type of connections does this valve have?

This valve is equipped with 1 inch female NPT threaded ends, designed for secure attachment to corresponding male NPT threaded pipes. It is approved for use with Schedule 40 pipe.

What is the purpose of the slow-close operation?

The slow-close gear operation is designed to eliminate water hammer, which can prevent damage to piping systems by reducing sudden pressure surges during valve closure. This ensures smoother system operation and extends component life.
