10 611-Mechanical Joint x Flange

Item Number: 905203
1 1
$3,551.29
Special Order
When Will it Ship: Contact for Lead Time
Estimated transit time: 2 to 5 Business Days

Brand - Febco
  • Size: 10 inch
  • Weight: 396.0 lb
  • Body Material: Ductile iron A536 GR 65-45-12
  • Coating: Fusion epoxy coated for corrosion resistance
  • Connection Type: Mechanical Joint x Flange
  • Maximum Working Pressure: 175 psi
  • Temperature Range: 32°F to 140°F
  • Fasteners: Stainless steel
  • Eliminates thrust block requirements

Description

The FEBCO Series 611 10 inch valve setter is constructed from fusion epoxy coated ductile iron, featuring a mechanical joint and a flange connection. It is engineered to simplify the installation of "N" series backflow prevention valves like the LF870V, LF876VST, and LF880V by providing integral support that eliminates thrust block requirements between elbows. This corrosion-resistant unit offers a maximum working pressure of 175 psi and operates in temperatures from 32°F to 140°F, ensuring durable performance for non-health hazard applications. Stainless steel fasteners enhance longevity. Item number 905203.

Help Me Connect

Compatibility & Connections

This valve setter is specifically designed to augment the installation of FEBCO MasterSeries "N" series backflow prevention valves, including models like LF870V, LF876VST, and LF880V. It features a mechanical joint connection on one end and a flanged connection on the other.

  • The mechanical joint side connects to compatible mechanical joint piping.
  • The flanged side connects to compatible ANSI AWWA C153 A21.53-88 flanges, typically found on the specified backflow preventers.

Mechanical joint accessories, flange bolts, and gaskets are not included except for the center joint, and may be required for installation. Consult local authorities for specific installation requirements.

View full details

Additional Details

This 10 inch valve setter, part of the FEBCO Series 611, features a mechanical joint on one side and a flange connection on the other, designed to facilitate the installation of specific backflow prevention valves.

Constructed of fusion epoxy coated ductile iron, it provides integral support to eliminate the need for thrust blocks between elbows in certain installations, specifically for "N" series backflow prevention valves.

Features

  • Corrosion resistant fusion epoxy coated body.
  • Eliminates the need for thrust blocks or other restraints at the point of installation.
  • Flanges conform to ANSI AWWA C153 A21.53-88 standards.
  • Lead Free* construction to comply with Lead Free* installation requirements.

Specifications

  • Size: 10 inch (250mm)
  • Body Material: Ductile iron A536 GR 65-45-12
  • Coating: Fusion epoxy coated internal and external AWWA C550
  • Bolts & Nuts Material: Stainless steel
  • Maximum Working Pressure: 175 psi (12.1 bar)
  • Temperature Range: 32°F to 140°F (0°C to 60°C)

Certificates & Approvals

  • Flanges: ANSI AWWA C153 A21.53-88
  • Lead Free* Construction

FAQs

What is the primary purpose of the FEBCO 611 valve setter?

The FEBCO 611 valve setter is designed to augment the installation of "N" series backflow prevention valves, such as the LF870V, LF876VST, and LF880V, by providing integral support and eliminating the need for thrust blocks between elbows.

What material is the 10 inch valve setter constructed from?

The valve setter is constructed from fusion epoxy coated ductile iron (A536 GR 65-45-12), offering excellent corrosion resistance for long-term durability.

What are the connection types for this valve setter?

This specific model features a mechanical joint connection on one end and an ANSI AWWA C153 A21.53-88 compliant flange connection on the other.

What is the maximum operating pressure and temperature range?

The maximum working pressure for this valve setter is 175 psi (12.1 bar), and it is designed to operate within a temperature range of 32°F to 140°F (0°C to 60°C).

Are mechanical joint accessories or flange bolts included?

Mechanical joint accessories, flange bolts, and gaskets are generally not included with the valve setter, except for the center joint. These components typically need to be sourced separately for installation.
