10 OSY GATE VALVE, GRV X GRV

Item Number: 10-48OSYG
1 1
$8,342.13
Special Order
When Will it Ship: Contact for Lead Time
Estimated transit time: 2 to 5 Business Days

Brand - Wilkins
  • Model: Zurn Wilkins 48OS&Y
  • Connection Type: Grooved x Grooved
  • Body Material: Epoxy coated ductile iron
  • Internal Materials: Stainless steel
  • Max Working Pressure: 250 psi
  • Max Working Temperature: 140°F
  • AWWA Compliant: C515, C-550
  • Low-lead law compliant

Description

The Zurn Wilkins 48OS&Y Resilient Wedge Gate Valve is a robust shut-off valve designed for potable water lines, irrigation systems, and waterworks connections. It features an epoxy coated ductile iron body and stainless steel internals for superior corrosion resistance. With grooved connections on both ends, it offers versatile installation and can be used independently or with Wilkins Backflow Preventers. This low-lead law compliant valve has a maximum working water pressure of 250 psi and is AWWA C515, C-550, IAPMO, and UL listed, ensuring high performance and reliability.

Help Me Connect

Connections

  • This valve features grooved connections on both ends for versatile installation within a grooved piping system.

Compatibility

  • Can be used as a stand-alone shut-off valve.
  • Compatible for use on Wilkins Backflow Preventers.
View full details

Additional Details

The Zurn Wilkins Model 48OS&Y Resilient Wedge Gate Valve with grooved connections is designed for shut-off applications in potable water lines, irrigation systems, and waterworks connections.

This gate valve can be used as a stand-alone product or in conjunction with Wilkins Backflow Preventers.

Features

  • Durable construction with an epoxy coated ductile iron body and stainless steel internals to resist corrosion.
  • Resilient wedge design for reliable shut-off.
  • Low-lead law compliant for safe potable water applications.

Specifications

  • Model: 48OS&Y Resilient Wedge Gate Valve
  • Connection Type: Grooved x Grooved
  • Body Material: Epoxy coated ductile iron
  • Internal Materials: Stainless steel
  • Maximum Working Water Pressure: 250 psi
  • Maximum Working Water Temperature: 140°F
  • Hydrostatic Test Pressure: 500 psi
  • Low-Lead Law Compliant: Yes

Certificates & Approvals

  • AWWA Compliant: C515, C-550
  • IAPMO® Listed
  • UL® Listed

FAQs

What is the primary use of the Zurn Wilkins 48OS&Y Gate Valve?

It is primarily used as a shut-off valve in potable water lines, irrigation systems, and waterworks connection applications to control water flow.

What type of connections does this gate valve have?

This specific valve features grooved connections on both ends (GRV x GRV), allowing for versatile and secure installation within grooved piping systems.

What materials are used in the construction of this valve?

The valve is constructed with an epoxy coated ductile iron body and features durable stainless steel internals, providing excellent resistance against corrosion and ensuring longevity.

What are the maximum working pressure and temperature ratings for this valve?

The maximum working water pressure for this valve is 250 psi, and it is rated for a maximum working water temperature of 140°F.

Is this gate valve compliant with low-lead laws and relevant industry standards?

Yes, this valve is low-lead law compliant. It is also AWWA C515 and C-550 compliant, IAPMO® Listed, and UL® Listed, verifying its adherence to industry standards for quality and safety.
