2 1/2 LF880V-LG-FS

Item Number: F122945
1 1
$6,852.00
Special Order
When Will it Ship: Contact for Lead Time
Estimated transit time: 2 to 5 Business Days

Brand - Febco
  • Product Type: Reduced Pressure Zone Backflow Preventer
  • Nominal Size: 2 1/2 inch
  • Lead Free Construction
  • Ductile Iron Body with ArmorTek® Coating
  • Stainless Steel Relief Valve Seat
  • Stainless Steel Check Components
  • Integrated Flood Sensor with SentryPlus Alert® Technology
  • N-Pattern Design, Less Shutoffs

Description

The 2 1/2 inch FEBCO LF880V-LG-FS is a Lead Free Reduced Pressure Zone Backflow Preventer Assembly, designed to protect industrial water services from high hazard fluids. Its ductile iron body features a patented 3-part ArmorTek® epoxy coating for advanced corrosion resistance, including microbial induced corrosion. Equipped with a stainless-steel relief valve seat and check components, it ensures maximum durability. This N-Pattern assembly includes an integrated SentryPlus Alert® flood sensor to detect continuous relief valve discharge, offering crucial early warning for potential flooding. This model is supplied without shutoff valves. Item number F122945.

Help Me Connect

The FEBCO LF880V-LG-FS Reduced Pressure Zone Backflow Preventer is designed for water services to industrial installations and applications where protection against high hazard (toxic) fluids is required. This assembly does not include shutoff valves, allowing for integration with existing or separately purchased shutoff components.

The integrated flood sensor with SentryPlus Alert® technology offers enhanced monitoring capabilities. An add-on sensor connection kit (sold separately) can extend flood monitoring. This sensor system is compatible with various alert systems, including:

  • Building Management Systems (BMS)
  • Cellular communication modules
  • Sensor Control Monitor for integration with BAS via RS-485 Modbus or the Nexa® platform through Wi-Fi
View full details

Additional Details

The 2 1/2 inch FEBCO LF880V-LG-FS Lead Free Reduced Pressure Zone Backflow Preventer Assembly is designed to protect against high hazard (toxic) fluids in water services for industrial installations and applications.

This assembly comes without shutoff valves and features a robust ductile iron body construction with advanced corrosion resistance provided by a patented 3-part ArmorTek® epoxy coating system.

Key Features

  • Lead Free Construction: Ensures compliance with lead-free standards.
  • Durable Body: Ductile iron body with patented 3-part ArmorTek® epoxy coating system designed to limit microbial induced (MIC) and exposed metal substrate corrosion.
  • Superior Components: Combines a stainless-steel relief valve seat and stainless-steel check components for maximum performance and extended durability.
  • Configurable N-Pattern Design: Offers flexible installation options.
  • Integrated Flood Sensor: Features a flood sensor with SentryPlus Alert® technology to detect continuous discharge from the relief valve, providing early warning for potential flooding events.

SentryPlus Alert® Technology Integration

  • Detects continuous relief valve discharge.
  • Add-on sensor connection kit available for extended flood monitoring on compatible assemblies.
  • Integrates with Sensor Control Monitor to deliver maintenance alerts to Building Automation Systems (BAS) via RS-485 Modbus or the Nexa® platform through Wi-Fi connectivity.

Specifications

  • Product Type: Reduced Pressure Zone Backflow Preventer
  • Nominal Size: 2 1/2 inch
  • Model: LF880V
  • Lead Free: Yes
  • Shutoffs: Less Shutoffs
  • Body Material: Ductile Iron
  • Body Coating: ArmorTek® Patented 3-part Advanced Epoxy
  • Relief Valve Seat: Stainless Steel
  • Check Components: Stainless Steel
  • Pattern: N-Pattern
  • Flood Sensor: SentryPlus Alert® Technology Included

FAQs

What is the primary application for the FEBCO LF880V-LG-FS backflow preventer?

This backflow preventer assembly is designed for water services in industrial installations and applications where protection against high hazard (toxic) fluids is critical.

Does this backflow preventer include shutoff valves?

No, the FEBCO LF880V-LG-FS assembly is supplied "less shutoffs," meaning the shutoff valves are not included and must be purchased separately or integrated with existing piping.

What material is the body made from, and how is it protected against corrosion?

The body is constructed from ductile iron and features a patented 3-part ArmorTek® advanced epoxy coating system, specifically designed to resist both microbial induced (MIC) and exposed metal substrate corrosion.

What is the function of the integrated flood sensor?

The integrated flood sensor with SentryPlus Alert® technology detects continuous discharge from the relief valve, providing an early warning system for potential flooding events and allowing for timely intervention.

How does the flood sensor communicate alerts?

When paired with an add-on connection kit, the sensor can relay alerts via Building Management Systems (BMS), cellular communication, or integrate with a Sensor Control Monitor for communication to BAS via RS-485 Modbus or the Nexa® platform via Wi-Fi.
