2 1/2 LF886V-DOSY-GPM-FS

Item Number: F683210
1 1
$12,534.00
Special Order
When Will it Ship: Contact for Lead Time
Estimated transit time: 2 to 5 Business Days

Brand - Febco
  • Lead Free construction
  • ArmorTek® powder coating for corrosion resistance
  • SentryPlus Alert® flood sensor for discharge detection
  • Ductile iron body with OSY resilient wedge gate valves
  • Stainless steel relief valve seat and check components
  • Detector bypass with GPM meter
  • Maximum Operating Pressure: 175 psi
  • Temperature Range: 33°F - 140°F

Description

This 2 1/2 inch FEBCO MasterSeries LF886V Reduced Pressure Zone Detector Backflow Preventer provides critical protection for potable water systems against high hazard backpressure and backsiphonage. Featuring lead-free construction, a durable ductile iron body with ArmorTek® corrosion-resistant coating, and stainless steel internal components for longevity. It includes a SentryPlus Alert® flood sensor to detect relief valve discharge and a metered bypass to monitor water usage. Designed for inline serviceability, this assembly ensures reliable performance for industrial applications. Ideal for systems requiring robust protection against toxic fluid contamination.

Help Me Connect

Flood Sensor Activation & Connectivity

The integrated flood sensor requires an add-on connection kit for activation and to communicate alerts. Without this kit, the sensor operates passively and will not relay signals. Connection kit options allow for diverse monitoring solutions:

  • Building Management Systems (BMS): For integration into existing building controls.
  • Cellular Communication: Enables remote alerts via call, email, or text.
  • Sensor Control Monitor: Facilitates integration with Building Automation Systems (BAS) via RS-485 Modbus or the Nexa® platform through Wi-Fi connectivity.
View full details

Additional Details

This 2 1/2 inch lead free FEBCO MasterSeries® LF886V Reduced Pressure Zone Detector Assembly (Type II) is engineered to protect potable drinking water systems from backpressure and backsiphonage of high hazard/toxic fluids, making it ideal for industrial installations and applications. The assembly is equipped with domestic OSY shutoff valves and a metered bypass for comprehensive water system management.

Advanced Protection & Monitoring

  • Features a flood sensor with SentryPlus Alert® technology to detect continuous discharge from the relief valve, enabling multi-channel alerts (call, email, text) to notify personnel of potential flooding.
  • Includes ArmorTek® powder coating, a patented three-part advanced epoxy system, applied to the ductile iron body and internal/external surfaces to resist microbial-induced corrosion (MIC) and protect exposed metal substrate.
  • Equipped with a compact detector bypass assembly with a GPM meter, capable of detecting potential underground water leaks and unauthorized water usage.

Durable & Serviceable Design

  • The main valve features stainless steel relief valve seat and stainless steel check components for maximum performance and extended durability.
  • Designed for inline serviceability, allowing for maintenance without special tools.
  • Incorporates captured modular spring assembly, reversible and replaceable discs, and field replaceable seats for ease of repair.
  • Constructed with a ductile iron valve body for robust performance.
  • The auxiliary bypass includes an inline serviceable 3/4" check assembly with a field replaceable seat and disc.

An add-on connection kit is required to activate the flood sensor. Without the connection kit, the flood sensor is a passive component that does not communicate with any other device.

Use of the flood sensor does not replace the need to comply with all required instructions, codes, and regulations related to installation, operation, and maintenance of this product, including the need to provide proper drainage in the event of a discharge. Watts® is not responsible for the failure of alerts due to connectivity issues, power outages, or improper installation.

Specifications

  • Model: LF886V-DOSY-GPM-FS
  • Product Type: Reduced Pressure Zone Detector Assembly (Type II)
  • Size: 2 1/2 inch
  • Main Valve Body Material: Ductile iron Grade 65-45-12
  • Relief Valve Body Material: Ductile iron Grade 65-45-12
  • Coating: ArmorTek powder coating
  • Shutoff Valves: OSY resilient wedge gate valve AWWA C515 (UL Classified and FM Approved)
  • Check Seats Material: Stainless steel
  • Relief Valve Seat Material: Stainless steel
  • Disc Holder Material: Stainless steel
  • Elastomer Disc Material: Silicone
  • Spring Material: Stainless steel
  • Clamp: AWWA C606

Performance Ratings

  • Maximum Working Pressure: 175 psi (12.1 bar)
  • Minimum Working Pressure: 20 psi (1.4 bar)
  • Hydrostatic Test Pressure: 350 psi (24.1 bar)
  • Hydrostatic Safety Pressure: 700 psi (48.3 bar)
  • Temperature Range: 33°F - 140°F (0.5°C ~ 60°C) continuous

Dimensions (Approximate)

  • Overall Length (A): 28 3/8 inches (721 mm)
  • Width (B): 12 1/8 inches (308 mm)
  • Height (F): 17 1/2 inches (445 mm)
  • Weight (OSY): 292 lbs (133 kg)

Certificates & Approvals

  • Foundation for Cross-Connection Control and Hydraulic Research at The University of Southern California (FOCCCHR-USC)
  • ASSE 1047
  • UL Classified (US & Canada)
  • FM Approved
  • IAPMO/cUPC
  • AWWA Standard C511 Compliant
  • CSA Connections Compliant to ASME B16.1 Class 125 & AWWA Class D Flange
  • CSA B64.4

FAQs

What is the primary purpose of the FEBCO LF886V backflow preventer?

The primary purpose of this 2 1/2 inch lead-free backflow preventer is to protect potable water systems from contamination due to backpressure and backsiphonage, especially in high hazard/toxic applications like industrial installations.

How does the ArmorTek® coating benefit this backflow preventer?

The ArmorTek® coating is a patented three-part advanced epoxy system applied to the ductile iron body. It is engineered to resist microbial-induced corrosion (MIC) and protect exposed metal surfaces, extending the life and reliability of the assembly.

What does the integrated flood sensor do, and how is it activated?

The integrated flood sensor with SentryPlus Alert® technology detects excessive water discharges from the relief valve. It requires an add-on connection kit to be activated and to relay multi-channel alerts (call, email, text) to personnel about potential flooding.

What is the maximum operating pressure and temperature range for this assembly?

The maximum working pressure for this 2 1/2 inch LF886V backflow preventer is 175 psi (12.1 bar). It can operate continuously within a temperature range of 33°F to 140°F (0.5°C to 60°C).

Are the internal components designed for durability and easy maintenance?

Yes, the main valve features stainless steel relief valve seats and stainless steel check components for maximum performance and durability. The design also allows for inline serviceability with captured modular spring assemblies, replaceable discs, and field replaceable seats, simplifying maintenance.
