2.5 OSY GATE VALVE, GRV X GRV

Item Number: 212-48OSYG
1 1
$2,038.30
Special Order
When Will it Ship: Contact for Lead Time
Estimated transit time: 2 to 5 Business Days

Brand - Wilkins
  • Valve Type: OS&Y Gate Valve
  • Nominal Size: 2.5 inch
  • End Connections: Grooved x Grooved
  • Body Material: Epoxy Coated Ductile Iron
  • Internal Materials: Stainless Steel
  • Maximum Working Water Pressure: 250 psi
  • Maximum Working Water Temperature: 140°F
  • AWWA C515 and C-550 Compliant

Description

The Zurn Model 48OS&Y gate valve is a 2.5 inch shut-off valve with grooved x grooved end connections, ideal for potable water lines, irrigation systems, and waterworks applications. Constructed with an epoxy coated ductile iron body and stainless steel internals, it offers superior corrosion resistance and durability. This valve can be used independently or in conjunction with Wilkins Backflow Preventers. It features a maximum working pressure of 250 psi and a maximum temperature of 140°F. Compliant with Lead Free laws, AWWA C515/C-550, IAPMO, and UL standards, it ensures reliable and safe performance. Item number 212-48OSYG.

Help Me Connect

Connections

  • This 2.5 inch OS&Y Gate Valve features grooved connections on both ends, designed for secure and reliable installation into grooved piping systems.
  • It is suitable for use in potable water lines, irrigation systems, and waterworks connection applications.
  • The valve can function as a standalone shut-off device or be integrated into systems utilizing Wilkins Backflow Preventers.
View full details

Additional Details

The Zurn Model 48OS&Y gate valve is engineered for reliable shut-off in potable water lines, irrigation systems, and waterworks connection applications. This 2.5 inch valve features grooved end connections for versatile installation and can be used as a standalone product or with Wilkins Backflow Preventers.

Construction & Design

  • Features an epoxy coated ductile iron body for durability and corrosion resistance.
  • Equipped with stainless steel internals to further protect against corrosion.
  • Designed to be Lead Free and low-lead law compliant for safe use in potable water systems.

Performance

  • Offers a maximum working water pressure of 250 psi.
  • Maintains functionality at a maximum working water temperature of 140°F.
  • Capable of withstanding a hydrostatic test pressure of 500 psi.

Specifications

  • Valve Type: OS&Y Gate Valve
  • Nominal Size: 2.5 inch
  • End Connections: Grooved x Grooved
  • Body Material: Epoxy Coated Ductile Iron
  • Internal Materials: Stainless Steel
  • Maximum Working Water Pressure: 250 psi
  • Maximum Working Water Temperature: 140°F
  • Hydrostatic Test Pressure: 500 psi

Certificates & Approvals

  • Lead Free
  • Low-Lead Law Compliant
  • AWWA Compliant C515
  • AWWA Compliant C-550
  • IAPMO® Listed
  • UL® Listed

FAQs

What is the primary application of the Zurn 2.5 inch OS&Y Gate Valve?

This Zurn Model 48OS&Y gate valve is primarily utilized for reliable shut-off in potable water lines, irrigation systems, and various waterworks connection applications.

What type of end connections does this gate valve feature?

The Zurn 2.5 inch OS&Y Gate Valve features grooved connections on both ends (GRV X GRV) for straightforward and versatile installation into compatible piping systems.

What materials are used in the construction of this valve?

The valve is constructed with an epoxy coated ductile iron body for robust durability and corrosion resistance, complemented by stainless steel internals for long-lasting performance.

What are the maximum working pressure and temperature ratings for this valve?

This gate valve has a maximum working water pressure rating of 250 psi and can operate effectively in water temperatures up to 140°F. It also has a hydrostatic test pressure of 500 psi.

Is this Zurn gate valve compliant with lead-free regulations?

Yes, this Zurn Model 48OS&Y Gate Valve is explicitly stated as Lead Free and low-lead law compliant, making it suitable for potable water applications where such regulations apply.
