2.5 PIV GATE VALVE, FLG X FLG

Item Number: 212-48PIV
1 1
$2,263.28
Special Order
When Will it Ship: Contact for Lead Time
Estimated transit time: 2 to 5 Business Days

Brand - Wilkins
  • Nominal Size: 2.5 inch
  • End Connections: Flanged x Flanged
  • Maximum Working Water Pressure: 250 psi
  • Maximum Working Water Temperature: 140°F
  • Body Material: Epoxy coated ductile iron
  • Internals: Stainless steel
  • Stem Type: Non-rising
  • AWWA Compliant: C515, C-550
  • UL® Listed

Description

This 2.5 inch Zurn Wilkins Model 48 resilient wedge gate valve is engineered for reliable shut-off control in potable water lines, irrigation systems, and waterworks connections. It features durable flanged x flanged end connections, allowing for versatile installation as a stand-alone component or with Wilkins Backflow Preventers. Constructed with an epoxy-coated ductile iron body and stainless steel internals, it offers superior corrosion resistance. The valve supports a maximum working pressure of 250 psi and temperatures up to 140°F, meeting low-lead laws and AWWA C515, C550, IAPMO, and UL listings.

Help Me Connect

Connections

  • The flanged x flanged end connections are designed for direct installation into piping systems with corresponding flanges.

Compatibility

  • This gate valve can be used as a stand-alone shut-off valve or integrated into systems that include Wilkins Backflow Preventers.
View full details

Additional Details

The Zurn Wilkins Model 48 Resilient Wedge Gate Valve with flanged x flanged connections is designed for reliable shut-off control in various water management applications.

It is commonly utilized on potable water lines, irrigation systems, and waterworks connections. This valve functions effectively as both a stand-alone product or when integrated with Wilkins Backflow Preventers.

Key Features

  • Features a non-rising stem design
  • Constructed with an epoxy coated ductile iron body for enhanced durability and superior corrosion resistance
  • Equipped with stainless steel internals to further protect against corrosion
  • Offers versatile installation due to its flanged end connections
  • Is fully low-lead law compliant

Specifications

  • Product Type: Resilient Wedge Gate Valve
  • Nominal Size: 2.5 inch
  • End Connections: Flanged x Flanged
  • Stem Type: Non-rising
  • Body Material: Epoxy coated ductile iron
  • Internal Material: Stainless steel
  • Maximum Working Water Pressure: 250 psi
  • Maximum Working Water Temperature: 140°F
  • Hydrostatic Test Pressure: 500 psi
  • Application: Potable water lines, irrigation systems, waterworks connections

Certificates & Approvals

  • AWWA Compliant: C515, C-550
  • IAPMO® Listed
  • UL® Listed
  • Low-lead law compliant

FAQs

What are the primary applications for the Zurn Wilkins Model 48 Gate Valve?

This gate valve is primarily used on potable water lines, irrigation systems, and waterworks connection applications for reliable shut-off control.

What type of connections does this 2.5 inch gate valve feature?

The 2.5 inch Zurn Wilkins Model 48 Gate Valve features flanged x flanged end connections, providing versatile installation options for compatible piping systems.

What is the maximum working pressure and temperature for this valve?

This valve has a maximum working water pressure of 250 psi and a maximum working water temperature of 140°F.

What materials are used in the construction of this gate valve?

The valve features an epoxy-coated ductile iron body and durable stainless steel internals, designed to resist corrosion and ensure longevity.

Is the Zurn Wilkins Model 48 Gate Valve compliant with low-lead laws?

Yes, this resilient wedge gate valve is low-lead law compliant and also meets AWWA C515, C-550, IAPMO, and UL listings.
