2 LF2000BM1-FP - GV

Item Number: 88007259
1 1
$4,437.00
Special Order
When Will it Ship: Contact for Lead Time
Estimated transit time: 2 to 5 Business Days

Brand - Ames
  • Size: 2 inch
  • Weight: 24.7 lb
  • Body Material: Lead Free cast copper silicon alloy
  • End Connections: Grooved
  • Maximum Working Pressure: 175 PSI
  • Temperature Range: 33°F – 140°F
  • Isolation Valves: Gear Operated Slow Close
  • Features: Two pre-wired tamper switches
  • Approvals: ASSE 1015, UL, CSA B64.4

Description

This 2 inch Lead Free Bronze Double Check Valve Backflow Preventer Assembly is designed to safeguard potable water supplies from non-potable contamination. It is ideal for protecting non-health hazard cross-connections by preventing reverse flow due to backsiphonage or backpressure. Key features include a lead free cast copper silicon alloy body, grooved end connections, gear operated slow close isolation valves, and two pre-wired tamper switches. With a maximum working pressure of 175 PSI and a temperature range of 33-140°F, it offers reliable performance. Approved for both horizontal and vertical installations, this assembly ensures compliance with national plumbing codes. ASSE 1015, UL Classified, and CSA B64.4 certified. Item number 88007259.

Help Me Connect

This 2 inch double check valve assembly features grooved end connections for straightforward installation into your piping system. It is approved for both horizontal and vertical installations, providing flexibility for various plumbing configurations. Ensure connections comply with AWWA C 606-11 Grooved end standards.

View full details

Additional Details

This 2 inch double check valve backflow preventer assembly prevents the reverse flow of contaminated non-potable water from entering the potable water supply. It is ideal for protecting against contaminants at the service line entrance and for cross-connections identified as non-health hazard applications, in accordance with national plumbing codes and water authority requirements.

Key Features

  • Features a lead free bronze body with gear operated slow close isolation valves.
  • Includes two pre-wired tamper switches and top mounted ball valve type test cocks.
  • Designed with grooved end connections and two positive seating check modules.
  • Offers ease of maintenance with only one top-entry access cover, requiring no special tools.
  • Boasts a compact and modular design with low pressure drop.
  • Approved for both horizontal and vertical "flow-up" installations.

Specifications

  • Size: 2 inch
  • Body Material: Lead Free cast copper silicon alloy
  • End Connections: Grooved
  • Isolation Valves: Gear Operated Slow Close
  • Tamper Switches: Pre-wired (2)
  • Test Cocks: Top mounted ball valve type
  • Maximum Working Pressure: 175 PSI (12.1 bar)
  • Temperature Range: 33°F – 140°F (0.5°C – 60°C)
  • Installation Orientation: Horizontal and Vertical "Flow-Up"
  • Maintenance: Single Top Entry Cover
  • Weight: 26.4 lbs (12 kgs)
  • Overall Length (A): 19 23/32 inches (500 mm)

Certificates & Approvals

  • Approved by the Foundation for Cross-Connection Control and Hydraulic Research at the University of Southern California (FCCCHR)
  • ASSE 1015 Listed
  • UL Classified (US & Canada)
  • IAPMO PO
  • AWWA Standard C510 Compliant
  • CSA B64.4
  • NFPA 13, 14, 16, 20, 22 & 24 Compliant

FAQs

What is the primary purpose of this backflow preventer assembly?

This 2 inch double check valve assembly is designed to prevent the reverse flow of contaminated non-potable water from entering the potable water supply, protecting against backsiphonage and backpressure at cross-connections.

What type of connections does this backflow preventer use?

The assembly features grooved end connections, designed for easy and secure installation into a compatible piping system.

What material is the body of this backflow preventer made from?

The body of this assembly is constructed from lead free cast copper silicon alloy, ensuring compliance with lead-free requirements for potable water applications.

Can this backflow preventer be installed in any orientation?

Yes, it is approved for both horizontal and vertical 'flow-up' installations, offering flexibility for various piping configurations.

What are the operating pressure and temperature limits for this device?

This backflow preventer has a maximum working pressure of 175 PSI (12.1 bar) and can operate within a temperature range of 33°F to 140°F (0.5°C to 60°C).
