2 LFAFBV-FP-T

Item Number: 88005712
1 1
$963.00
Special Order
When Will it Ship: Contact for Lead Time
Estimated transit time: 2 to 5 Business Days

Brand - Ames
  • Valve Size: 2 Inch
  • Weight: 23.7 lb
  • Connection Type: Female NPT Threaded
  • Body Material: Lead Free Cast Copper Silicon Alloy
  • Maximum UL/FM Rated Working Pressure: 400 PSI
  • Operation: Gear Operated Quarter-Turn
  • Wiring Options: Normally Open or Normally Closed
  • Approvals: UL Listed, FM Approved, NSF/ANSI 372
  • Internal Tamper Switches: Yes (2)

Description

This 2 inch Lead Free Gear Operated Ball Valve with NPT Threaded Ends is UL/FM rated for 400 PSI in fire protection systems. Constructed from lead-free cast copper silicon alloy with a chrome-plated brass ball and PTFE seats, it ensures durability and a positive shut-off. Its slow-close, gear-operated design eliminates water hammer. Featuring integrated supervisory switches with a reversible wiring box, it can be wired Normally Open or Normally Closed for flexible system integration. Approved for both indoor and outdoor use, this valve meets NSF/ANSI 372 lead-free standards.

Help Me Connect

Connections

This 2 inch LFAFBV-FP Series ball valve features female NPT threaded ends designed for direct connection to male NPT threaded pipe of the same 2 inch nominal pipe size. It is suitable for use with Schedule 40 pipe in fire protection systems.

View full details

Additional Details

The 2 inch LFAFBV-FP Series lead free gear operated slow close ball valve is UL/FM rated for 400 psi service in fire protection systems. This full-port bronze body ball valve is designed with NPT threaded ends for use in indoor and outdoor applications.

Key Features

  • Slow open and slow closing operation eliminates water hammer
  • Can be wired as either Normally Open or Normally Closed for versatile control
  • Reversible supervisory switch box simplifies electrical wiring access
  • Gear operated quarter-turn operation with a clockwise-to-close handle
  • Includes two standard internal tamper switches and an external position indicating flag
  • Lead-free cast copper silicon alloy body with chrome-plated brass ball and brass stem
  • PTFE seats provide low torque and positive shut off
  • Approved for use with Schedule 40 pipe
  • Ergonomic handle design for ease of use

The wetted surface of this product contacted by consumable water contains less than 0.25% of lead by weight, meeting lead-free requirements.

Specifications

  • Valve Type: 2-Piece Full Port Ball Valve
  • Operation: Gear Operated Quarter-Turn
  • Valve Size: 2 Inch
  • End Connections: Female NPT Threaded
  • Maximum UL/FM Rated Working Pressure: 400 PSI (27.6 bar)
  • Hydrostatic Test Pressure: 900 PSI (62.0 bar)
  • Temperature Range: 33°F - 180°F (0.5°C - 82°C)

Materials

  • Body Material: Lead Free Cast Copper Silicon Alloy
  • Ball Material: Chrome Plated Brass
  • Stem Material: Brass
  • Stem Packing Material: Virgin PTFE
  • Seat Material: Virgin PTFE
  • Box/Cover Material: Bronze ASTM B584 Alloy B44
  • Yoke Material: LEAD-FREE Copper Silicon Alloy
  • Screw Material: Brass
  • Traveler Nut Material: Brass

Certificates & Approvals

  • UL Listed
  • FM Approved
  • NSF Certified to NSF/ANSI 372
  • NFPA 11, 13, 14, 15, 16, 20, 22, 24 Compliant
  • Conforms to NFPA 13 Section 6.7.1

FAQs

What is the primary application of this LFAFBV-FP ball valve?

This 2 inch LFAFBV-FP series ball valve is specifically designed for use in fire protection systems, where it is UL/FM rated for 400 PSI service.

What type of pipe connections does this valve utilize?

This particular model of the LFAFBV-FP series features 2 inch female NPT threaded ends, making it suitable for connection to corresponding male NPT threaded pipe.

Is this ball valve suitable for both indoor and outdoor installations?

Yes, the LFAFBV-FP series ball valve is approved and rated for both indoor and outdoor use in various fire protection system environments.

How does the "slow close" feature benefit a fire protection system?

The slow open and slow closing operation of this valve is designed to eliminate water hammer, protecting the piping system from sudden pressure surges and potential damage.

What does "lead-free" mean for this product?

The wetted surface of this product, which comes into contact with consumable water, contains less than 0.25% of lead by weight, complying with NSF/ANSI 372 lead-free requirements.
