3/4 LFFBV-M 6-10

Item Number: 0792525
1 1
$177.75
Special Order
When Will it Ship: Contact for Lead Time
Estimated transit time: 2 to 5 Business Days

Brand - Watts
  • Size: 3/4 inch
  • Weight: 3.6 lb
  • Connection: 3/4 inch Male NPT x Female NPT
  • Design: Full Port Ball Valve
  • Operation: Quarter Turn
  • Application: 6 to 10 inch Backflow Preventers
  • Lead Free: Wetted surface contains less than 0.25% lead

Description

This 3/4 inch Watts test cock (0792525) is a lead-free full port ball valve designed for use with 6 to 10 inch backflow preventers. It features male NPT x female NPT threads for secure installation. The quarter-turn operation ensures reliable flow control in various plumbing systems. This test cock is also suitable for use as an isolation valve for gauges or small equipment lines where a 3/4 inch connection is required. Its lead-free construction ensures compliance with regulations for potable water applications. Item number 0792525.

Help Me Connect

Connections

This 3/4 inch test cock features a Male NPT thread on one side and a Female NPT thread on the other. It is specifically designed to fit 6 to 10 inch lead free backflow preventers. It can also be used as an isolation valve for pressure gauges or small equipment lines requiring 3/4 inch NPT connections.

View full details

Additional Details

This 3/4 inch test cock is designed for use with 6 to 10 inch lead free backflow preventers, isolation valves for gauges, or small equipment lines.

Connections

  • Features Male NPT x Female NPT threads.

Features

  • Lead free full port ball valve design.
  • Quarter turn valve for easy operation.
  • Compatible with 6 to 10 inch backflow preventers.

Specifications

  • Body Material: Brass
  • Size: 3/4 inch
  • Connection Type: MNPT x FNPT
  • Valve Design: Full Port Ball Valve
  • Lead Free Compliance: Wetted surfaces contain less than 0.25% lead by weight

FAQs

What is the primary use of this test cock?

This 3/4 inch test cock is primarily used with 6 to 10 inch lead free backflow preventers. It can also serve as an isolation valve for pressure gauges or small equipment lines.

What are the connection types for this test cock?

This test cock features a 3/4 inch Male NPT (National Pipe Taper) thread on one end and a 3/4 inch Female NPT thread on the other end.

Is this product lead-free?

Yes, this test cock is lead-free. The wetted surfaces of this product that contact consumable water contain less than 0.25% lead by weight, meeting industry standards.

What size backflow preventers is this test cock compatible with?

This test cock is designed for compatibility with 6 inch to 10 inch backflow preventers.

What kind of valve design does it feature?

It features a full port ball valve design, which allows for maximum flow and minimal pressure drop when fully open. It operates with a quarter-turn mechanism.
