6 450 DCDA DI BODY GAL MTR BFLY GRV X GRV

Item Number: 6-450DABG
1 1
$21,068.35
Special Order
When Will it Ship: Contact for Lead Time
Estimated transit time: 2 to 5 Business Days

Brand - Wilkins
  • Size: 6 inch
  • Type: Double Check Detector Backflow Assembly
  • Body Material: Epoxy-coated ductile iron
  • End Connections: Butterfly Grooved x Grooved
  • Design: n-Pattern for tight spaces
  • Leak Detection: Metered bypass system
  • Check Type: Wilkins Compound Check for low headloss
  • Certifications: ASSE® Listed, CSA® Certified, AWWA Compliant

Description

The Zurn Wilkins 6-inch 450DA Double Check Detector Backflow Assembly, SKU 6-450DABG, is engineered for reliable protection against backsiphonage and backpressure in low health hazard and fire protection water lines. Its n-Pattern design facilitates installation in compact or retrofit applications. Constructed with an epoxy-coated ductile iron body for corrosion resistance, it features a metered bypass system for accurate leak detection and unauthorized water use. The Wilkins Compound Check ensures low headloss and consistent performance. This assembly is ASSE® Listed, CSA® Certified, and AWWA Compliant.
View full details

Additional Details

The Zurn Wilkins 450DA Double Check Detector Backflow Assembly is designed to protect water lines in low health hazard and fire protection applications from both backsiphonage and backpressure.

This 6-inch model features an n-Pattern design for versatile installation in tight locations and includes a metered bypass system to effectively detect leaks and unauthorized water usage.

Key Features

  • Protects against backsiphonage and backpressure
  • Ideal for low health hazard and fire protection applications
  • n-Pattern design allows for use in compact enclosures and easy retrofit installations
  • Equipped with an innovative metered bypass system to detect leaks and unauthorized water use
  • Features the Wilkins Compound Check for reliable performance and improved flow characteristics with low headloss
  • Epoxy-coated ductile iron body provides protection against corrosion
  • Valve assembly comes standard with OS&Y gate valves

Specifications

  • Model: 450DA
  • Size: 6 inch
  • Type: Double Check Detector Backflow Assembly (DCDA)
  • Body Material: Ductile Iron
  • Body Coating: Epoxy-coated
  • End Connections: Butterfly Valve, Grooved x Grooved
  • Pattern: n-Pattern
  • Bypass: Metered Bypass System
  • Check Type: Wilkins Compound Check
  • Valves: OS&Y Gate Valves

Certificates & Approvals

  • ASSE® Listed
  • CSA® Certified
  • AWWA Compliant

FAQs

What is the primary function of the Zurn Wilkins 450DA backflow preventer?

The Zurn Wilkins 450DA Double Check Detector Backflow Assembly is designed to protect water distribution systems from contamination due to backsiphonage and backpressure in low health hazard, fire protection applications.

What type of body material and coating does this backflow preventer feature?

This backflow preventer features a durable ductile iron body, which is epoxy-coated to provide excellent protection against corrosion, ensuring long-lasting performance.

How does the 'n-Pattern' design benefit installation?

The 'n-Pattern' design of the 450DA is specifically engineered for compact enclosures and tight locations, making it ideal for both new installations and retrofitting existing systems where space is limited.

Does the Zurn Wilkins 450DA include a system for leak detection?

Yes, the 450DA is equipped with an innovative metered bypass system. This system efficiently and effectively detects small leaks and any unauthorized water usage on the downstream side.

What certifications does the 450DA backflow preventer hold?

The Zurn Wilkins 450DA is ASSE® Listed, CSA® Certified, and AWWA Compliant, ensuring it meets rigorous industry standards for performance and safety.
