6 7001-1-Clean Out-Flange x Flange

Item Number: 0690892
1 1
$11,972.25
Special Order
When Will it Ship: Contact for Lead Time
Estimated transit time: 2 to 5 Business Days

Brand - Ames
  • Size: 6 inch
  • Weight: 314.0 lb
  • Body Material: Epoxy coated fabricated steel
  • Connection Type: Flanged ends
  • Cleanout: One port
  • Maximum Working Pressure: 175 psi
  • Strainer Element: 304 stainless steel
  • Approvals: CULUS Listed, FM Approved, UPC Approved
  • Protects water spray systems from clogging

Description

This 6 inch Ames Series 7001 fire service strainer is designed to protect non-potable water spray fire protection systems from clogging by trapping foreign particles. It features a durable epoxy-coated fabricated steel body with flanged connections and a 304 stainless steel strainer element. Approved by CULUS, FM, and UPC for fire systems, this strainer has a maximum working pressure of 175 psi and includes a single cleanout port for easy maintenance. It is ideal for safeguarding critical fire system components from large debris.

Help Me Connect

Connections

  • The 6 inch Ames Series 7001 strainer features flange x flange connections adhering to AWWA Class "D" standards.
  • It is typically installed upstream of other devices in a fire protection system, such as meters, backflow preventers (or detector check valves), and flow alarms, to protect them from damage by large particles.
View full details

Additional Details

This 6 inch Ames Fire & Waterworks Series 7001 fire service strainer is designed for use in non-potable water spray fire protection systems to prevent clogging from particles.

It features an epoxy-coated fabricated steel body with flanged connections and a single cleanout port.

Key Features

  • Epoxy coated fabricated steel strainer body
  • Designed to protect water spray systems from clogging due to foreign particles
  • Large solids trap to minimize screen blockage
  • Removable filter for replacement and repair without removing the body from the line
  • Flush outlet provided for each strainer
  • 304 stainless steel strainer element with 0.25 inch diameter perforations

Connections

  • Flange x flange connections
  • Flanges: AWWA Class "D"

WARNING: It is illegal to use this product in any plumbing system providing water for human consumption, such as drinking or dishwashing, in the United States. Consult local water authority, building, and plumbing codes before installation.

Specifications

  • Size: 6 inch
  • Body & Cover Material: Fusion-bonded epoxy coated steel
  • Screen Material: 304 stainless steel
  • Perforation Diameter: .25 inch
  • Clean-Out Plug Material: Brass or Bronze
  • Connection Type: Flanged
  • Flange Standard: AWWA Class "D"
  • Maximum Working Pressure: 175 psi (12.1 bar)
  • Water Temperature: Up to 140°F (60°C)

Certificates & Approvals

  • CULUS Listed 321
  • FM Approved Class 5551
  • UPC Approved for fire systems

FAQs

What is the primary use of this strainer?

This 6 inch Ames Series 7001 fire service strainer is used in non-potable water spray fire protection systems to prevent clogging that can be caused by particles fouling sprinkler heads.

What are the connection types for this strainer?

This strainer features flange x flange connections, designed to AWWA Class "D" standards, allowing for secure integration into piping systems.

What materials are used in the construction of this strainer?

The body and cover are made from fusion-bonded epoxy coated steel, while the strainer element is 304 stainless steel with .25 inch perforations. The clean-out plug is brass or bronze.

What is the maximum operating pressure and temperature?

The strainer has a maximum working pressure of 175 psi (12.1 bar) and can handle water temperatures up to 140°F (60°C).

Is this product approved for use in fire protection systems?

Yes, this strainer is CULUS Listed 321, FM Approved Class 5551, and UPC Approved for fire systems.
