8 LF880V-LG RP-FS

Item Number: F122949
1 1
$24,520.50
Special Order
When Will it Ship: Contact for Lead Time
Estimated transit time: 2 to 5 Business Days

Brand - Febco
  • Size: 8 inch
  • Weight: 639.0 lb
  • Body Material: Lead Free Ductile Iron
  • Coating: Patented 3-part ArmorTek® Epoxy
  • Relief Valve Seat: Stainless Steel
  • Check Components: Stainless Steel
  • Flood Sensor: SentryPlus Alert® Technology Included
  • Design: Configurable N-Pattern
  • Application: High hazard (toxic) fluids in industrial water services

Description

This 8 inch lead free reduced pressure zone backflow preventer assembly is engineered for industrial water services, providing critical protection against high hazard (toxic) fluids. It features a durable lead free ductile iron body with a patented 3-part ArmorTek epoxy coating system for superior corrosion resistance, including protection against microbial induced corrosion. Stainless-steel relief valve seats and check components ensure extended performance and reliability. The assembly includes a flood sensor with SentryPlus Alert technology to detect continuous relief valve discharge, offering proactive monitoring capabilities for potential flooding events. It is designed with a configurable N-Pattern for versatile installation and is supplied without shutoff valves. Item number F122949.

Help Me Connect

Connections & Compatibility

This 8 inch reduced pressure zone backflow preventer assembly is designed for use in water services for industrial installations and applications to protect against high hazard (toxic) fluids. It is supplied without integral shutoff valves, requiring separate installation of appropriate shutoffs upstream and downstream if needed for maintenance or isolation. The included flood sensor with SentryPlus Alert technology is designed to detect continuous relief valve discharge. This sensor can be extended for flood monitoring using an add-on connection kit (sold separately) for integration with Building Automation Systems (BAS) via RS-485 Modbus or the Nexa platform by Wi-Fi, or through BMS/cellular communication.

View full details

Additional Details

This 8 inch lead free MasterSeries(R) configurable reduced pressure zone backflow preventer assembly helps protect against high hazard (toxic) fluids in water services for industrial installations and applications.

This assembly is provided without the shutoff valves.

Features

  • Lead free ductile iron body construction
  • Patented 3-part ArmorTek(R) epoxy coating system designed to limit microbial induced (MIC) and exposed metal substrate corrosion
  • Stainless-steel relief valve seat and stainless-steel check components for maximum performance and durability
  • Configurable N-Pattern design
  • Includes a flood sensor with SentryPlus Alert(R) technology to detect continuous discharge from the relief valve
  • Add-on sensor connection kit available to extend flood monitoring on compatible assemblies (sold separately)
  • Integrates with the Sensor Control Monitor to deliver maintenance alerts to BAS via RS-485 Modbus or the Nexa platform by Wi-Fi connectivity

Specifications

General

  • Product Type: Reduced Pressure Zone Backflow Preventer Assembly
  • Size: 8 inch
  • Pattern: N-Pattern

Materials

  • Body Material: Lead Free Ductile Iron
  • Body Coating: Patented 3-part ArmorTek(R) Epoxy
  • Relief Valve Seat: Stainless Steel
  • Check Components: Stainless Steel

Sensors & Monitoring

  • Flood Sensor: Included, with SentryPlus Alert(R) Technology
  • Sensor Integration: Compatible with add-on connection kits for BMS, cellular communication, Sensor Control Monitor (RS-485 Modbus, Nexa Wi-Fi)

Certificates & Approvals

  • Not specified in source material.

FAQs

What is the primary application of this backflow preventer assembly?

This backflow preventer assembly is primarily used in water services for industrial installations and applications to protect against high hazard (toxic) fluids.

Does this assembly come with shutoff valves?

No, this 8 inch reduced pressure zone backflow preventer assembly is supplied without the shutoff valves. These would need to be procured and installed separately if required.

What type of coating is used on the body of this backflow preventer?

The ductile iron body features a patented 3-part ArmorTek® epoxy coating system. This advanced coating is designed to resist both microbial induced (MIC) and exposed metal substrate corrosion.

What is the function of the included flood sensor?

The flood sensor with SentryPlus Alert® technology detects continuous discharge from the relief valve. It can be integrated with add-on connection kits (sold separately) to relay alerts for potential flooding events to monitoring systems.

What materials are used for the internal components to ensure durability?

This backflow assembly utilizes a stainless-steel relief valve seat and stainless-steel check components, which are chosen for maximum performance, durability, and extended valve life.
