Ames 6" Colt 200 Butterfly Shut-Off Valves

Item Number: 0191225
1 1
$9,651.85
Special Order
When Will it Ship: Contact for Lead Time
Estimated transit time: 2 to 5 Business Days

Brand - Ames
  • Size: 6 inch
  • Weight: 205.0 lb
  • Housing Material: 304 Stainless Steel
  • Valve Type: Grooved Gear Operated Butterfly
  • Maximum Working Pressure: 175 psi
  • Wetted Surface Lead Content: < 0.25%
  • Installation: Horizontal, Vertical, N-Pattern
  • Check Mechanism: Patented Tri-Link
  • Approvals: AWWA C510-97, ASSE 1015, UL, FM, NSF/ANSI 61-G

Description

The Ames 6 inch Colt 200 Series Lead Free Double Check Valve Assembly is designed to prevent backflow of non-potable water into a potable water supply in non-health hazard applications, such as fire sprinkler systems. Constructed with a 304 stainless steel body and featuring grooved gear-operated butterfly shutoff valves with tamper switches, it ensures reliable protection. Its compact design includes patented Tri-Link check modules for low pressure loss and a single access sleeve for easy, tool-free maintenance. This assembly is rated for a maximum working pressure of 175 psi and is approved for various installation orientations.

Help Me Connect

Connections

  • The Ames 6 inch Colt 200 Double Check Valve Assembly features grooved end connections, allowing for integral pipeline adjustment during installation.
  • The grooved gear-operated butterfly valves are equipped with tamper switches that can integrate with monitoring systems for added security.
  • This assembly is suitable for installation in horizontal, vertical, or N pattern orientations to fit various piping configurations.
View full details

Additional Details

The Ames 6 inch Colt 200 Series Lead Free Double Check Valve Assembly prevents backflow of non-potable substances into the potable water supply, ideal for non-health hazard applications such as fire sprinkler systems.

This compact and modular assembly features a stainless steel body, two Tri-Link check valves, and grooved gear-operated butterfly valves with tamper switches. It is designed for easy maintenance with a single access sleeve and does not require special tools for service.

Key Features

  • 6 inch Lead Free Double Check Valve Assembly
  • 304 Stainless Steel housing and sleeve
  • Grooved gear-operated butterfly shutoff valves with tamper switches
  • Patented Tri-Link check modules provide lowest pressure loss
  • Compact design and 70% lighter than traditional models
  • Allows for horizontal, vertical, or N pattern installations
  • Unmatched ease of serviceability with no special tools required
  • Groove fittings for integral pipeline adjustment
  • Replaceable check disc rubber
  • Wetted surfaces contain less than 0.25% lead by weight

Important Note: This is a non-stock, special order item and could take up to 2 weeks or more to deliver. All non-stock items are non-refundable. Please ensure you order carefully, and contact us with any questions before placing your order.

Specifications

General

  • Size: 6 inch
  • Product Series: Colt C200, C200N
  • Assembly Type: Double Check Valve
  • Application: Non-health hazard backflow prevention
  • Wetted Surface Lead Content: Less than 0.25% by weight
  • Installation: Horizontal, Vertical up, N-Pattern horizontal
  • Maximum Working Pressure: 175 psi (12.1 bar)
  • Temperature Range: 33°F - 140°F (0.5°C - 60°C)

Materials

  • Housing & Sleeve: 304 (Schedule 40) Stainless steel
  • Elastomers: EPDM, Silicone, Buna 'N'
  • Tri-Link Checks: Noryl®, Stainless steel
  • Check Discs: Reversible silicone or EPDM
  • Test Cocks Body: Lead Free Bronze
  • Pins & Fasteners: 300 Series Stainless steel
  • Springs: Stainless steel

Certificates & Approvals

  • Approved by the Foundation for Cross-Connection Control and Hydraulic Research at The University of Southern California (FCCCHR-USC)
  • AWWA C510-97
  • ASSE 1015
  • CSA B64.5
  • UL Classified
  • FM Approved
  • NSF Certified to NSF/ANSI 61-G

Dimensions (6 inch C200BFG)

  • Length (A): 36.5 inches (927 mm)
  • Width (C): 10 inches (254 mm)
  • Height (H): 33.25 inches (845 mm)
  • Approximate Weight (C200BFG): 117 lbs (53 kg)
  • Approximate Weight (C200NBFG): 157 lbs (71 kg)

FAQs

What is the primary use of the Ames 6 inch Colt 200 Double Check Valve Assembly?

Its primary use is to prevent backflow of non-toxic pollutants from entering a potable water supply system, making it ideal for non-health hazard applications like fire sprinkler systems.

What materials are used in the construction of this backflow preventer?

The housing and sleeve are made of 304 Schedule 40 stainless steel. Elastomers include EPDM, silicone, and Buna 'N', while Tri-Link checks are Noryl and stainless steel. Test cocks feature lead-free bronze bodies.

What is the maximum operating pressure and temperature for this assembly?

The maximum working pressure is 175 psi (12.1 bar), and the operating temperature range is 33°F to 140°F (0.5°C to 60°C).

Does this backflow preventer require special tools for maintenance?

No, the design of the Colt 200 Series Double Check Valve Assembly allows for unmatched ease of serviceability, and no special tools are required for maintenance or removal of the Tri-Link check modules.

What installation orientations are supported?

This assembly is approved for horizontal, vertical up, or "N" pattern horizontal installations, offering flexibility to suit various piping configurations.
