Wilkins AG-10 Air Gap Drain Fitting

Item Number: AG-10
Skip to product information
1 of 1
Regular price $699.66
Special Order
When Will it Ship: Contact for Lead Time
Estimated transit time: 2 to 5 Business Days

Brand - Wilkins

  • Model: AG-10
  • Compatible with: 8"-10" Model 475V RP Backflow Preventers
  • Outlet Connection: 4" NPT
  • Body Material: Epoxy-painted cast grey iron
  • Bolt Material: Zinc-plated steel
  • Prevents cross connection with potable water supply
  • Certified to: ANSI/ASME A 112.1.2
  • Designed for indoor installations

Description

The Wilkins AG-10 Air Gap Drain Fitting is essential for indoor installations of 8"-10" Model 475V Reduced Pressure Principle Backflow Preventers. It effectively connects a drain pipe to the backflow preventer, safely directing nuisance water discharge away. This fitting is crucial for preventing cross-contamination between the drain and the potable water supply. Constructed from durable epoxy-painted cast grey iron with zinc-plated steel bolts, it offers long-lasting performance and corrosion resistance. It features an iron inlet with an elbow and a 4" NPT outlet. Item number AG-10.

Help Me Connect

Compatibility

  • The Wilkins AG-10 Air Gap Fitting is compatible with 8" - 10" Model 475V Reduced Pressure Principle Backflow Preventers.
  • It is also stated to be available for all Wilkins Reduced Pressure Principle Assemblies.

Connections

The fitting features an iron inlet with an elbow for connection to the backflow preventer's relief port. The bottom of the unit provides 4" Female NPT outlet connections, allowing it to be easily mounted to the body of any drain line made of standard piping material, directing discharge to a safe location.

View full details

Collapsible content

Additional Details

The Wilkins AG-10 Air Gap Drain Fitting is designed for indoor installations of 8" - 10" Model 475V Reduced Pressure Principle Backflow Preventers.

Its primary use is to connect a drain pipe to the backflow preventer, effectively directing nuisance water discharge to a safe drain.

Purpose

  • Eliminates the risk of a cross connection between the drain and the potable water supply.
  • Reduces downtime associated with attaching a drain line to a Reduced Pressure Principle Assembly.

Connections

  • Features an iron inlet with an elbow.
  • Equipped with 4" NPT outlet connections on the bottom.

Construction

  • Constructed from an epoxy-painted cast grey iron elbow for durability.
  • Utilizes zinc-plated steel bolts to resist corrosion and ensure long-lasting effectiveness.

Specifications

  • Model: AG-10
  • Compatibility: 8" - 10" Model 475V Reduced Pressure Principle Backflow Preventers
  • Inlet Connection: Iron with elbow
  • Outlet Connection: 4" NPT
  • Body Material: Epoxy-painted cast grey iron
  • Bolt Material: Zinc-plated steel

Certificates & Approvals

  • ANSI/ASME A 112.1.2

FAQs

What is the primary use of the Wilkins AG-10 Air Gap Fitting?

The primary use is to connect a drain pipe to 8" - 10" Model 475V Reduced Pressure Principle Backflow Preventers, directing nuisance water discharge to a safe drain.

What specific backflow preventers is the AG-10 compatible with?

It is specifically compatible with 8" - 10" Model 475V Reduced Pressure Principle Backflow Preventers, and generally available for all Wilkins Reduced Pressure Principle Assemblies.

What type of connections does the AG-10 have?

It has an iron inlet with an elbow for the backflow preventer connection and a 4" NPT outlet connection on the bottom for the drain pipe.

What materials is the AG-10 made from?

The elbow is made of epoxy-painted cast grey iron, and the bolts are zinc-plated steel, ensuring durability and corrosion resistance.

How does the AG-10 prevent cross-contamination?

The air gap design physically separates the drain and potable water supply, eliminating the possibility of a cross connection and maintaining water safety.
