Wilkins AG-12 Air Gap Drain Fitting

Item Number: AG-12
Skip to product information
1 of 1
Regular price $227.27
Special Order
When Will it Ship: Contact for Lead Time
Estimated transit time: 2 to 5 Business Days

Brand - Wilkins

  • Compatible with Wilkins Model 375/375XL Backflow Preventers
  • Weight: 0.44 lb
  • Designed for 1-1/4 inch - 2 inch backflow preventer sizes
  • Features a composite inlet connection
  • 3 inch IPS slip outlet connection for drain pipe
  • Eliminates cross-connection to potable water supply
  • Constructed with epoxy-painted cast grey iron elbow
  • Includes zinc-plated steel bolts for corrosion resistance
  • Approved to ANSI/ASME A 112.1.2 standard

Description

The Wilkins AG-12 Air Gap Drain Fitting is an essential component for indoor installations of 1-1/4 inch to 2 inch Wilkins Model 375/375XL Reduced Pressure Principle Backflow Preventers. It ensures the safe disposal of nuisance water discharge by directing it to a drain, critically eliminating any cross-connection between the drain and the potable water supply. Constructed with a durable epoxy-painted cast grey iron elbow and zinc-plated steel bolts, this fitting offers reliable performance. It features a composite inlet and a 3-inch IPS slip outlet, making it compatible with standard drain lines.

Help Me Connect

Compatibility & Connections

The Wilkins AG-12 Air Gap Fitting is specifically designed for use with Wilkins Model 375/375XL Reduced Pressure Principle Backflow Preventers in sizes ranging from 1-1/4 inch to 2 inch. It attaches directly to the relief port of these devices for indoor installations. The fitting features a composite inlet and connects to standard drain piping via a 3 inch IPS slip outlet connection, effectively directing any relief valve discharge to a safe drain and preventing cross-connection with potable water.

View full details

Collapsible content

Additional Details

The Wilkins AG-12 Air Gap Drain Fitting is designed for indoor installations of all 1-1/4 inch to 2 inch Model 375/375XL Reduced Pressure Principle Backflow Preventers.

Its primary use is to connect a drain pipe to the backflow preventer, directing nuisance water discharge to a safe drain, while crucially eliminating any cross connection between the drain and the potable water supply.

Construction & Features

  • Features an epoxy-painted cast grey iron elbow for durability.
  • Equipped with zinc-plated steel bolts to resist corrosion and ensure long-lasting effectiveness.
  • Designed to mount easily to the body of any drain line made of standard piping material.

Connections

  • Utilizes a composite inlet connection.
  • Provides a 3 inch IPS slip outlet connection for direct attachment to a drain pipe.

Specifications

  • Compatible Backflow Preventers: Wilkins Model 375/375XL
  • Compatible Backflow Preventer Sizes: 1-1/4 inch - 2 inch
  • Inlet Connection: Composite
  • Outlet Connection: 3 inch IPS Slip
  • Body Material: Epoxy-painted cast grey iron
  • Bolt Material: Zinc-plated steel

Certificates & Approvals

  • ANSI/ASME A 112.1.2

FAQs

What is the primary purpose of the Wilkins AG-12 Air Gap Fitting?

The AG-12 is designed for indoor installations of Reduced Pressure Principle Backflow Preventers. It connects a drain pipe to the backflow preventer, directing nuisance water discharge to a safe drain.

What backflow preventer models is the AG-12 compatible with?

It is specifically compatible with all 1-1/4 inch to 2 inch Wilkins Model 375/375XL Reduced Pressure Principle Backflow Preventers.

What are the connection types for the AG-12 Air Gap Fitting?

The fitting features a composite inlet connection and a 3 inch IPS slip outlet connection, allowing it to be mounted to standard drain piping.

What materials are used in the construction of the AG-12?

The AG-12 is constructed with an epoxy-painted cast grey iron elbow. It includes zinc-plated steel bolts for secure and corrosion-resistant installation.

Does this air gap fitting prevent cross-contamination?

Yes, a fundamental function of the AG-12 Air Gap Fitting is to eliminate the potential for a cross-connection between the drain system and the potable water supply, ensuring water safety.
