2.5 LF880V-DNRS-FS

Item Number: F683140
1 1
$10,273.93
Special Order
When Will it Ship: Contact for Lead Time
Estimated transit time: 2 to 5 Business Days

Brand - Febco
  • Assembly Size: 2 1/2 inch
  • Weight: 260.0 lb
  • Lead Free construction
  • Body Material: Ductile Iron with ArmorTek® epoxy coating
  • SentryPlus Alert® flood sensor technology
  • Domestic Non-Rising Stem (NRS) shutoff valves
  • Stainless steel relief valve seat and check components
  • Protects against high hazard (toxic) fluids
  • Configurable N-Pattern design

Description

This 2 1/2 inch FEBCO LF880V-DNRS-FS is a lead free MasterSeries® reduced pressure zone backflow preventer assembly. It protects water services in industrial installations from high hazard (toxic) fluids. Key features include a durable ductile iron body with patented ArmorTek® epoxy coating for advanced corrosion resistance, a stainless-steel relief valve seat, and stainless-steel check components for extended life. The assembly also incorporates SentryPlus Alert® flood sensor technology to detect continuous relief valve discharge, with options for remote monitoring integration. It features domestic non-rising stem shutoff valves and a configurable N-Pattern design for versatile installation. Item number F683140.

Help Me Connect

Assembly Components

  • This reduced pressure zone backflow preventer assembly features domestic non-rising stem shutoff valves for isolation, test cocks for verification, spring loaded check valves, and a pressure differential relief valve for protection against backpressure and back-siphonage.

SentryPlus Alert® Flood Sensor Connectivity

  • The integrated SentryPlus Alert® flood sensor detects continuous discharge from the relief valve. For remote monitoring and alerts, it can be paired with an add-on connection kit (sold separately).
  • Connection kit options include those for BMS (Building Management Systems), cellular communication, or the Sensor Control Monitor.
  • The Sensor Control Monitor enables integration with BAS (Building Automation Systems) via RS-485 Modbus or the Nexa® platform through Wi-Fi connectivity.
View full details

Additional Details

This 2 1/2 inch lead free MasterSeries® configurable reduced pressure zone backflow preventer assembly is designed to help protect against high hazard (toxic) fluids in water services for industrial installations and applications.

The assembly includes domestic non-rising stem shutoff valves, test cocks, spring loaded check valves, and a pressure differential relief valve. Its ductile iron body is fused with a patented 3-part ArmorTek® epoxy coating, providing advanced corrosion resistance by limiting microbial induced (MIC) and exposed metal substrate corrosion.

Features

  • Lead free construction ensures compliance with health safety standards.
  • Patented 3-part ArmorTek® advanced epoxy coating system enhances durability and extends valve life by resisting microbial induced (MIC) and exposed metal substrate corrosion.
  • Equipped with a flood sensor with SentryPlus Alert® technology to detect continuous discharge from the relief valve, preventing potential flooding events.
  • Integrates with a Sensor Control Monitor (when paired with an add-on connection kit) to deliver maintenance alerts to BAS via RS-485 Modbus or the Nexa® platform by Wi-Fi connectivity.
  • Includes a stainless-steel relief valve seat and stainless-steel check components for maximum performance and durability.
  • Field reversible relief valve for flexible installation and maintenance.
  • Stainless steel springs provide reliable operation.
  • Configurable N-Pattern design allows for versatile installation configurations.

Specifications

  • Assembly Size: 2 1/2 inch
  • Valve Type: Reduced Pressure Zone Backflow Preventer Assembly
  • Body Material: Ductile Iron
  • Body Coating: Patented 3-part ArmorTek® Advanced Epoxy Coating System
  • Shutoff Valves: Domestic Non-Rising Stem (NRS)
  • Relief Valve Seat: Stainless Steel
  • Check Components: Stainless Steel
  • Spring Material: Stainless Steel
  • Configuration: N-Pattern (Configurable)
  • Flood Detection: SentryPlus Alert® Flood Sensor Technology
  • Hazard Protection: High Hazard (Toxic) Fluids
  • Lead Free: Yes

FAQs

What does this backflow preventer protect against?

This 2 1/2 inch FEBCO LF880V-DNRS-FS assembly is designed to protect water services against backflow from high hazard (toxic) fluids in industrial and commercial installations.

What is the body material and coating of this assembly?

The body is constructed from ductile iron and features a patented 3-part ArmorTek® advanced epoxy coating system. This coating is designed to resist microbial induced (MIC) and exposed metal substrate corrosion, ensuring long-term durability.

Does this backflow preventer have flood detection capabilities?

Yes, it includes SentryPlus Alert® technology with a flood sensor to detect continuous discharge from the relief valve. This helps prevent potential flooding and allows for alert integration with optional connection kits.

How can the flood sensor be integrated for remote alerts?

When paired with an add-on connection kit (sold separately), the flood sensor can integrate with Building Management Systems (BMS), cellular communication, or a Sensor Control Monitor. The Sensor Control Monitor enables connection to BAS via RS-485 Modbus or the Nexa® platform through Wi-Fi.

What type of shutoff valves are included with this assembly?

This assembly comes with domestic non-rising stem (NRS) shutoff valves, which are commonly used for isolation in backflow prevention systems.
