2.5 LF886V-OSY-CFM-FS

Item Number: F683223
1 1
$12,534.00
Special Order
When Will it Ship: Contact for Lead Time
Estimated transit time: 2 to 5 Business Days

Brand - Febco
  • Size: 2 1/2 inch
  • Weight: 240.0 lb
  • Lead Free Construction: Less than 0.25% lead by weight
  • Coating: ArmorTek® advanced epoxy for corrosion resistance
  • Flood Sensor: Detects excessive relief valve discharge
  • Shutoff Valves: OSY resilient wedge gate valves
  • Bypass Meter: CFM (Cubic Feet per Minute)
  • Maximum Working Pressure: 175 psi
  • Temperature Range: 33°F - 140°F

Description

The FEBCO 2 1/2 inch LF886V Reduced Pressure Zone Detector Assembly (Type II) protects potable water systems from high hazard backpressure and backsiphonage. This lead-free unit features ArmorTek® corrosion-resistant coating on ductile iron components and OSY shutoff valves. It includes a flood sensor with SentryPlus Alert® technology to detect and notify personnel of excessive relief valve discharge, requiring an add-on connection kit for activation. The bypass assembly incorporates a CFM water meter to monitor for leaks or unauthorized water usage. With a maximum working pressure of 175 psi and a temperature range of 33°F to 140°F, it offers reliable performance for industrial and commercial applications.

Help Me Connect

Flood Sensor Connectivity

This backflow preventer assembly includes an integrated flood sensor with SentryPlus Alert® technology, designed to detect excessive water discharges from the relief valve. To activate the sensor and enable multichannel alerts (call, email, text), an add-on connection kit is required. Without this kit, the flood sensor operates as a passive component and will not communicate with other devices.

End Connections

  • The assembly's end connections are compliant to ASME B16.1 Class 125 and AWWA Class D Flange standards.
  • It is available for both Horizontal (N-Pattern) and Vertical Up (Z-Pattern) orientations.

Proper drainage is critical for installation. While the gap drain handles normal discharge, the floor drain size may need to be designed to prevent water damage from a complete failure condition. Do not reduce the drain line size from the air gap fitting. Installation must comply with all required instructions, codes, and regulations. Inquire with governing authorities for local installation requirements.

View full details

Additional Details

This FEBCO 2 1/2 inch lead free MasterSeries LF886V Reduced Pressure Zone Detector Assembly (Type II) is designed to protect potable water systems from backpressure and backsiphonage in high hazard/toxic applications where local codes mandate protection.

It features a flood sensor with SentryPlus Alert® technology to detect excessive water discharges from the relief valve, notifying personnel of potential flooding.

Construction & Design

  • Constructed with a ductile iron valve body and OSY resilient wedge gate valves.
  • All iron components are coated with ArmorTek®, a patented three-part advanced epoxy system, providing integrated protection against microbial-induced corrosion (MIC) and exposed metal substrate corrosion.
  • Main valve features a stainless steel relief valve seat and stainless steel check components for maximum performance and durability.
  • Designed for inline serviceability without special tools.
  • Incorporates a captured modular spring assembly, reversible and replaceable discs, and field replaceable seats.
  • Auxiliary bypass includes a CFM (cubic feet per minute) water meter to detect potential underground leaks or unauthorized water usage.

Flood Sensor Activation

  • The integrated flood sensor relays a signal that triggers a multichannel alert (call, email, text) to notify personnel about potential flooding events.
  • An add-on connection kit is required to activate the flood sensor. Without this kit, the flood sensor functions as a passive component and will not communicate with other devices.

Specifications

  • Model: LF886V (Type II)
  • Size: 2 1/2 inch
  • Lead Content: Less than 0.25% by weight (wetted surface)
  • Coating: ArmorTek® powder coating (internal and external surfaces)
  • Detector Bypass: CFM (Cubic Feet per Minute) metered bypass

Materials

  • Main Valve Body: Ductile iron Grade 65-45-12
  • Relief Valve Body: Ductile iron Grade 65-45-12
  • Shutoff Valves: OSY resilient wedge gate valve AWWA C515 (UL Classified and FM Approved)
  • Check Seats: Stainless steel
  • Relief Valve Seat: Stainless steel
  • Disc Holder: Stainless steel
  • Elastomer Disc: Silicone
  • Spring: Stainless steel
  • Clamp: AWWA C606

Pressure & Temperature

  • Maximum Working Pressure: 175 psi
  • Minimum Working Pressure: 20 psi
  • Hydrostatic Test Pressure: 350 psi
  • Hydrostatic Safety Pressure: 700 psi
  • Temperature Range: 33°F - 140°F (0.5°C - 60°C) continuous

Certificates & Approvals

  • Foundation for Cross-Connection Control and Hydraulic Research at The University of Southern California (FCCCHR-USC)
  • ASSE 1047
  • UL Classified (US & Canada)
  • FM Approved
  • IAPMO/CUPC
  • AWWA Standard C511 Compliant
  • CSA B64.4
  • End Connections: Compliant to ASME B16.1 Class 125 & AWWA Class D Flange

FAQs

What is the primary use of the FEBCO LF886V assembly?

The FEBCO LF886V assembly is primarily used to protect potable drinking water systems from contamination due to backpressure and backsiphonage in high hazard/toxic applications, adhering to local governing water utility codes.

Does this backflow preventer assembly include a flood sensor?

Yes, it includes an integrated flood sensor with SentryPlus Alert® technology. This sensor detects excessive water discharges from the relief valve and can relay signals for multichannel alerts when paired with an add-on connection kit.

What does 'Lead Free' mean for this product?

The term 'Lead Free' indicates that the wetted surface of this product, which comes into contact with consumable water, contains less than 0.25% of lead by weight, complying with low lead installation requirements.

What kind of corrosion protection does the LF886V feature?

The iron components of this backflow preventer are coated with ArmorTek®, a patented three-part advanced epoxy system. This coating is engineered to reduce microbial-induced corrosion (MIC) and protect exposed metal substrates, enhancing durability.

What are the operating pressure and temperature limits for this assembly?

This assembly has a maximum working pressure of 175 psi and a minimum working pressure of 20 psi. Its continuous operating temperature range is 33°F to 140°F (0.5°C to 60°C).
