8 LF880V-DNRS RP-FS

Item Number: F683144
1 1
$36,780.74
Special Order
When Will it Ship: Contact for Lead Time
Estimated transit time: 2 to 5 Business Days

Brand - Febco
  • Size: 8 inch
  • Weight: 1115.0 lb
  • Lead Free Construction: < 0.25% lead by weight
  • Body Material: Ductile Iron Grade 65-45-12
  • Coating: ArmorTek® advanced epoxy system
  • Shutoff Valves: Domestic Non-Rising Stem (NRS)
  • Flood Sensor: SentryPlus Alert® technology
  • Maximum Working Pressure: 175 psi
  • Temperature Range: 33°F - 140°F

Description

The 8-inch FEBCO MasterSeries LF880V Lead Free Reduced Pressure Zone assembly is designed for high-hazard backflow protection in potable water systems. Its ductile iron body features ArmorTek® advanced epoxy coating for superior corrosion resistance and extended life. Equipped with domestic non-rising stem shutoff valves and a SentryPlus Alert® flood sensor, it detects excessive relief valve discharge for timely alerts. With stainless steel internal components and compliance with low lead requirements, this backflow preventer ensures durability and water safety for industrial applications.

Help Me Connect

Installation & Sensor Connectivity

  • This assembly supports both horizontal N-pattern and vertical up Z-pattern installation to suit various piping configurations.
  • The integrated SentryPlus Alert® flood sensor requires an add-on connection kit to be activated. These kits can enable communication via BMS, cellular networks, or the Sensor Control Monitor for integration with BAS via RS-485 Modbus or the Nexa® platform through Wi-Fi. Without a connection kit, the sensor remains a passive component.
View full details

Additional Details

This 8 inch Lead Free MasterSeries® LF880V Reduced Pressure Zone assembly is designed to protect potable drinking water systems against backpressure and backsiphonage conditions for high hazard (toxic) applications in accordance with Local Governing Water Utility Code.

Key Features

  • Features a SentryPlus Alert® flood sensor to detect excessive water discharges from the relief valve, providing alerts about potential flooding when activated by an add-on connection kit.
  • Ductile iron valve body construction is fused with ArmorTek®, a patented three-part advanced epoxy coating system engineered to reduce microbial-induced corrosion (MIC) and protect exposed metal substrates.
  • Utilizes stainless steel relief valve seat and stainless steel check components for maximum performance and durability.
  • Designed for inline servicing without requiring special tools, with modules accessed through independently top entry covers.
  • Supports both horizontal N-pattern or vertical up Z-pattern installation.
  • Includes domestic non-rising stem (NRS) shutoff valves.
  • The assembly features modular and repairable pressure differential relief valve with captured modular spring assembly, reversible and replaceable discs, and field replaceable seats.

NOTICE: Use of the flood sensor does not replace the need to comply with all required instructions, codes, and regulations related to installation, operation, and maintenance of this product, including the need to provide proper drainage in the event of a discharge. Watts® is not responsible for the failure of alerts due to connectivity issues, power outages, or improper installation.

Specifications

  • Size: 8 inch
  • Main Valve Body Material: Ductile Iron Grade 65-45-12
  • Relief Valve Body Material: Ductile Iron Grade 65-45-12
  • Coating: ArmorTek® powder coating (3-part advanced epoxy system)
  • Shutoff Valves: Domestic Non-Rising Stem (NRS) resilient wedge gate valve AWWA C509
  • Check Seats Material: Stainless steel
  • Relief Valve Seat Material: Stainless steel
  • Disc Holder Material: Stainless steel
  • Elastomer Disc Material: Silicone
  • Spring Material: Stainless steel
  • Clamp Standard: AWWA C606

Pressure & Temperature Ratings

  • Maximum Working Pressure: 175 psi (12.1 bar)
  • Minimum Working Pressure: 20 psi (1.4 bar)
  • Hydrostatic Test Pressure: 350 psi (24.1 bar)
  • Hydrostatic Safety Pressure: 700 psi (48.3 bar)
  • Temperature Range: 33°F - 140°F (0.5°C ~ 60°C) continuous

Certificates & Approvals

  • Approved by: Foundation for Cross-Connection Control and Hydraulic Research at the University of Southern California (FCCCHR-USC)
  • Listed: ASSE 1013
  • Classified: UL (US & Canada)
  • Approved: FM
  • Certified: IAPMO/CUPC
  • Compliant to: AWWA Standard C511
  • End Connections: Compliant to ASME B16.1 Class 125 & AWWA Class D Flange
  • Certified: CSA B64.4

FAQs

What is the primary purpose of this backflow preventer?

This backflow preventer is designed to protect potable drinking water systems from contamination due to backpressure and backsiphonage conditions in high hazard/toxic applications, commonly found in industrial installations.

What does "Lead Free" construction mean for this product?

“Lead Free” indicates that the wetted surfaces of this product, which come into contact with consumable water, contain less than 0.25% of lead by weight, complying with low lead installation requirements.

How does the integrated flood sensor function?

The SentryPlus Alert® flood sensor detects excessive water discharges from the relief valve. When activated with an add-on connection kit, it can relay signals to trigger multichannel alerts (call, email, text) to notify personnel of potential flooding.

What type of shutoff valves are included with this assembly?

This assembly includes domestic non-rising stem (NRS) resilient wedge gate valves, which comply with AWWA C509 standards.

What are the maximum operating pressure and temperature ratings for this unit?

This backflow preventer has a maximum working pressure of 175 psi (12.1 bar) and a continuous operating temperature range of 33°F to 140°F (0.5°C to 60°C).
