8 LF880V-OSY RP-FS

Item Number: F122961
1 1
$39,225.32
Special Order
When Will it Ship: Contact for Lead Time
Estimated transit time: 2 to 5 Business Days

Brand - Febco
  • Size: 8 inch
  • Weight: 1165.0 lb
  • Lead Free: Yes
  • Body Material: Ductile Iron
  • Coating: ArmorTek® Epoxy Coating
  • Shutoff Valves: OSY (Outside Stem and Yoke)
  • Relief Valve Seat: Stainless-steel
  • Flood Sensor: SentryPlus Alert® Technology
  • Configurable N-Pattern Design

Description

The 8 inch lead-free FEBCO MasterSeries® reduced pressure zone backflow preventer assembly safeguards water services in industrial installations from high hazard (toxic) fluids. It features a durable ductile iron body with patented ArmorTek® 3-part epoxy coating for superior corrosion resistance and extended valve life. Equipped with OSY shutoff valves, stainless-steel relief valve seat, and stainless-steel check components, this assembly ensures maximum performance. Integrated SentryPlus Alert® flood sensor technology detects continuous discharge, relaying alerts for potential flooding events and integrating with building management systems. Item number F122961.

Help Me Connect

The 8 inch Lead Free Reduced Pressure Zone Backflow Preventer is engineered for use in water services within industrial installations and applications where protection against high hazard (toxic) fluids is critical. This assembly is designed to connect into the main water line of such facilities.

Its outside stem and yoke (OSY) shutoff valves provide a clear visual indication of the valve's open or closed status, aiding in system monitoring and maintenance.

The integrated SentryPlus Alert® flood sensor offers advanced monitoring capabilities. For remote alerts and system integration, an add-on connection kit is required (purchased separately). These kits allow for communication via BMS, cellular networks, or a Sensor Control Monitor, which enables integration with Building Automation Systems (BAS) through RS-485 Modbus or the Nexa® platform by Wi-Fi.

View full details

Additional Details

This 8 inch lead free MasterSeries® configurable reduced pressure zone backflow preventer assembly is designed to protect against high hazard (toxic) fluids in water services to industrial installations and applications.

This assembly with outside stem and yoke shutoff valves consists of a lead free body, test cocks, spring loaded check valves, and a pressure differential relief valve.

Construction & Durability

  • Features a ductile iron body construction
  • Protected by a patented 3-part ArmorTek® advanced epoxy coating system designed to limit both microbial induced (MIC) and exposed metal substrate corrosion
  • Combines the use of a stainless-steel relief valve seat and stainless-steel check components for maximum performance and extended valve life
  • Configurable N-Pattern design

Advanced Sensor Technology

  • Contains a flood sensor with SentryPlus Alert® technology to detect continuous or excessive discharge from the relief valve
  • When paired with an add-on connection kit, the sensor activates to relay alerts for potential flooding events
  • Sensor connection kit options include BMS, cellular communication, and the Sensor Control Monitor
  • The Sensor Control Monitor enables integration with BAS via RS-485 Modbus or the Nexa® platform by Wi-Fi

Specifications

  • Size: 8 inch
  • Body Material: Lead Free Ductile Iron
  • Coating: ArmorTek® 3-part advanced epoxy coating
  • Valve Type: Reduced Pressure Zone Backflow Preventer
  • Shutoff Valves: OSY (Outside Stem and Yoke)
  • Relief Valve Seat Material: Stainless-steel
  • Check Components Material: Stainless-steel
  • Pattern: N-Pattern
  • Sensor: SentryPlus Alert® Flood Sensor

FAQs

What is the primary application of the 8 LF880V-OSY RP-FS backflow preventer?

This 8-inch lead-free reduced pressure zone backflow preventer is designed to protect water services against high hazard (toxic) fluids in industrial installations and applications.

What materials are used in the construction of this backflow preventer?

The body is constructed from lead-free ductile iron and features a patented 3-part ArmorTek® advanced epoxy coating. It also utilizes stainless-steel for the relief valve seat and check components for enhanced durability.

Does this backflow preventer include flood detection capabilities?

Yes, it incorporates a flood sensor with SentryPlus Alert® technology designed to detect continuous discharge from the relief valve. This sensor can relay alerts for potential flooding events when paired with an add-on connection kit.

What type of shutoff valves does this assembly use?

This backflow preventer assembly is equipped with Outside Stem and Yoke (OSY) shutoff valves, providing clear visual indication of valve position.

Can the flood sensor be integrated with a Building Automation System (BAS)?

Yes, through connection kit options, the flood sensor can integrate with a BAS via RS-485 Modbus or the Nexa® platform through Wi-Fi, using the Sensor Control Monitor.
